Explore the Lateral Strain Test Apparatus

In the field of materials science and engineering, it is crucial to have a deep understanding of the performance of materials under various stresses. As a device specifically used to test the lateral stress-related properties of materials, the transverse stress test device plays an indispensable role.

1. Application scenarios and standards

The lateral strain test device is primarily designed to determine whether a socket sustains any damage under the standard - defined conditions when it is subjected to transverse stress exerted by an electrical appliance. Its specific applications are as follows:

Durability Testing under Lateral Strain: Through simulating the lateral strain generated when an electrical appliance is inserted into the socket, this device can test the socket's ability to endure such stress without getting damaged. This helps in evaluating the long - term reliability and service life of the socket under practical usage scenarios.

Multi - standard Compliance: The device fully complies with the technical requirements of standards such as IEC60884, VDE0620, and GB/T2099.1 - 2021. By adhering to these international and national standards, it ensures the authority and reliability of the test results. This compliance also enables manufacturers to meet the regulatory requirements in different regions and provides a consistent benchmark for quality assessment across the industry.

2. Usage and configuration

When using the lateral strain test device, each specimen is usually mounted on a vertical surface, and then the corresponding plug is inserted into the socket and a hanging weight (usually 5N) is hung for one minute. Then the mounting plate is rotated 90° and the test is carried out again. The whole process is carried out four times in total, and the socket should be rotated 90° after each plug-in.

Device configuration includes:

Test plug: such as GB6A two-pin plug, GB10A three-pin plug, GB16A three-pin plug, or can be customized as per drawings,

‌Weight‌: Usually a 5N hanging weight.

3. Maintenance

3.1 The test plugs are precision parts, please handle with care during use to avoid striking the pins and changing their sizes.

3.2 After the test, the instrument should be cleaned and maintained
