Static Flexibility Test Apparatus
1. Introduction
The static flexibility test apparatus is designed to meet the test requirements of IEC60227-2 clause 3.5 and GB/T5023.2 clause 3.5 for testing the flexibility of cables with conductor cross-sectional areas ≥2.5mm2.
2. Parameter
Working Power | AC220V/50Hz |
Control units | Meter+buttons |
Height from ground | 1.5m above |
Clamp A | Fixed end |
Clamp B | Moveable end |
Move direction | horizontal |
Moveable distance | ≤1.0m |
Minimum space | 0.2m |
Cable rotate | Manually |
